Metering of flavoring agents by LEWA metering systems in the process of brewing alcohol-free beers

Securing a consistent taste and quality is of highest importance to producers of beverages.

However, this is particularly challenging to achieve in food technological processes which require as much accuracy as beer brewing. This is because ingredients like flavoring agents have to be added at exactly the right time and in the right proportion.

LEWA ecodos pumps of the sanitary/hygienic series meet the demands of this hygienic process because of their high reliability and metering precision.

Solution

LEWA’s solution for the challenging task of injecting flavoring agents in beer production:

  • A LEWA ecodos metering pump is used for the injection of flavoring agents
  • Aromatics are stored in a reservoir equipped with an agitator, a cleaning ball, and two level switches
  • A filter at the suction side of the pump prevents clogging of pump valves
  • The flow rate of the pump is adjusted continuously with an electromagnetic flow meter and control loop to keep the proportion with the beer flow rate
  • Fully PLC-controlled. However, the system also works “manually”. In this case the flow rate is adjusted by a potentiometer
  • At the discharge side a contactor protects the pump from overpressure
  • All materials that are in contact with the product have a roughness of less than Ra < 0.8μm (SS 316 L)
Injection of flavoring agents, scheme

Background

There are three general types of flavorings used in the food and beverage industry:

TypeDescription
Natural flavoring agentsFlavoring agents obtained from plant or animal raw materials by microbiological or enzymatic processes. They can be either used in their natural state or processed for human consumption, but must not contain any nature-identical or artificial substances.
Nature-identical flavoring agentsFlavoring agents obtained from synthesis or isolation in chemical processes. These substances are chemically and organoleptically identical to flavorings naturally present in products intended for human consumption. They cannot contain any artificial flavoring substances.
Synthetic flavoring agentsFlavorings not present in natural products intended for human consumption, whether processed or not. These are typically produced by fractional distillation and additional chemical manipulation of naturally sourced chemicals. Although they are chemically different, the sensory characteristics are the same as natural flavors.
